STARTER MOTOR 12V 12T CW 35MT DELCO STYLE DXS627

STARTER MOTOR 12V 12T CW 35MT DELCO STYLE DXS627

$1,184.70
$1,184.70
Tax included. Shipping calculated at checkout.

Description


Starter Motor 12V 12T CW 35MT Delco Style – DXS659

The OEX Starter Motor DXS659 is a heavy-duty 12V, 12-tooth clockwise starter motor built to 35MT Delco-style specifications. Designed for high-torque diesel applications, this starter delivers strong cranking performance and reliable engine starts in agricultural, industrial, and heavy-duty commercial equipment.

Engineered with robust construction and high-output capability, this unit ensures dependable operation under continuous load, making it suitable for tractors, combines, trucks, and industrial diesel engines.

Key Features

  • High output 4.3kW performance – strong cranking power for large diesel engines
  • 12V heavy-duty system compatibility – suited for industrial and agricultural use
  • 12-tooth pinion (CW rotation) – precise and reliable engagement
  • 35MT Delco-style design – direct OE replacement fitment
  • Heavy-duty 3-hole mounting system – stable and secure installation
  • Dry clutch system – durable and consistent performance
  • Insulated return design – improved electrical reliability
  • Brand new unit – not remanufactured
  • 1-year warranty

Specifications

  • Voltage: 12V
  • Power Rating: 4.3kW
  • Teeth: 12
  • Rotation: Clockwise (CW)
  • Series: 35MT
  • Flange Diameter: 92mm
  • Mount Centres A/B/C: 127mm
  • Mount Hole Diameter: 13mm
  • Overall Length: 355mm
  • Pinion Diameter: 46mm
  • Pinion at Rest: 48mm
  • Starter Mount Type: 3 Hole
  • Clutch Type: Dry
  • Insulated Return: No
  • Weight: 10.16kg
  • Suits Unit Make: Delco
  • Unit Type: New

Vehicle / Equipment Applications

Commonly fitted to:

Case IH Equipment

  • 1420 / 1440 / 1460 / 1470 / 1480 / 1482 Combines
  • 6788 / I-6588 Tractors
  • DT436 / DT466 / DT466C diesel engine applications

AGCO Allis Tractors

  • 9435 / 9455 – Series 40E Diesel (1996→)

Ford Cargo Trucks

  • 1621 / 2419 Series – 3208 Diesel Platform & Tractor (1987–1993)

Cummins Engines

  • ISC 8.3 Diesel Standalone Engines (1997→)
  • ISL 8.9 Diesel Standalone Engines (2010→)

Western Star Trucks

  • 4700 Series (ISL 260 / ISL 400 engine variants)

Always confirm fitment using OE number, Delco reference, or vehicle specifications before purchase.

Performance & Reliability

The DXS659 starter motor is built for demanding heavy-duty environments where consistent cranking power is essential. Its 4.3kW output delivers strong starting performance for large displacement diesel engines, while the rugged 35MT Delco-style construction ensures durability under vibration, heat, and continuous use.

Ideal for agricultural machinery, combines, trucks, and industrial diesel applications requiring dependable starting performance.

Why Choose OEX?

  • Trusted aftermarket brand across Australia & New Zealand
  • Designed for OE-style fitment and heavy-duty reliability
  • Built for industrial, agricultural, and commercial applications
  • Backed by strict quality control and testing standards
